KWh Class 1 ADL200 Din Rail Energy Meter With Digital LCD Display
Contact Person : Dina Huang
Phone Number : 18761502682
WhatsApp : +8618761502682
| Minimum Order Quantity : | >=1 Pieces | Price : | $35.00 |
|---|---|---|---|
| Packaging Details : | It is packed in a crash bag and then put into a cardboard box. | Supply Ability : | 1000000 Piece/Pieces per Month |
| Place of Origin: | Jiangsu, China | Brand Name: | Acrel |
|---|---|---|---|
| Model Number: | ADL100-ET |
|
Detail Information |
|||
| Display Type: | LCD | Phase: | Single Phase |
|---|---|---|---|
| Measuring Energy Range: | 000000.00~999999.99kWh | Accuracy Class: | 1 Class |
| Output Voltage: | 220V | Operating Temperature: | -25℃~55℃ |
| Dimensions: | 36mm*96 Mm*70mm | Current: | 10-60A |
| Standards Compliant: | IEC 62053-21:2003 | Communication: | RS485 Modbus-RTU Communication |
| Option Function F: | Multi Tariff Energies | Port: | Shanghai |
| High Light: | 220VAC Din Rail Energy Meter,60A Din Rail Energy Meter,220VAC 1 phase energy meter |
||
Product Description
|
Voltage
|
Reference voltage
|
|
AC 220V
|
|
||
|
|
Reference frequency
|
|
45-65 Hz
|
|
||
|
|
Consumption
|
|
<10VA( Single phase)
|
|
||
|
Current
|
Maximum
|
|
60A
|
|
||
|
|
Starting current
|
|
0.004 Ib
|
|
||
|
|
Consumption
|
|
<4VA(Maximum current)
|
|
||
|
Measurement performance
|
Accuracy of active kWH
|
|
Class 1
|
|
||
|
|
Standards complicant
|
|
IEC 62053-21:2003
|
|
||
|
Pulse
|
Pulse width
|
|
80+20 ms
|
|
||
|
|
Pulse constant
|
|
3200 imp/kWH
|
|
||
|
Communication
|
Interface
|
|
RS485
|
|
||
|
|
Protocol
|
|
Modbus-RTU
|
|
||
|
Outling
|
L*W*H(mm)
|
|
36*88*70
|
|
||
|
Environment
|
Temperature
|
|
Operating:-25℃~55℃；Storage:-40℃~70℃
|
|
||
|
|
Humidity
|
|
≦95% (No condensation)
|
|
||
|
|
Altitude
|
|
<2000m
|
|
||
