KWh Class 1 ADL200 Din Rail Energy Meter With Digital LCD Display
Contact Person : Dina Huang
Phone Number : 18761502682
WhatsApp : +8618761502682
| Minimum Order Quantity : | 1 pcs | Packaging Details : | Individually packed in big carton |
|---|---|---|---|
| Delivery Time : | 3 days | Supply Ability : | 10000/month |
| Place of Origin: | China | Brand Name: | Acrel |
|---|---|---|---|
| Certification: | CE | Model Number: | ADL10-E |
|
Detail Information |
|||
| Accuracy: | KWh Class 1，Kvarh Class 2 | Frequency: | 50HZ |
|---|---|---|---|
| Auxiliary Power Supply(self Supply): | AC 220V（L-N），range：154~264Vac | Pulse Output: | Pulse Output KWh/kvarh |
| Consumption: | <10VA(Single Phase) | Installation: | DIN 35mm |
| Dimension(L*W*H): | 18*88*70 Mm | Starting Current: | 0.004Ib |
| High Light: | DIN35mm Din Rail Energy Meter,0.004Ib Din Rail Energy Meter,DIN35mm Single Phase Smart Meter |
||
Product Description
ADL10 din rail energy meter adopts DIN35mm din rail installation with LCD display,it can measure electric parameters and has energy pulse output, RS485 communication,which has the advantages of small size, high precision, good reliability and convenient installation.
Technical Features
| Items | Features | |
|
Environment |
Temperature | -40℃~125℃ |
| Humidity | ≤95% | |
| atmospheric pressure | 86kPa~106kPa | |
|
ATE100M/100/200 Active wireless temperature sensor |
Wireless frequency | 470MHz |
| Communication distance | 150m in open area | |
| Sampling frequency | 25s | |
| Transmitting frequency | 25s-5min | |
| Power source | Battery | |
| Installation | Magnetic / bolted /Belt | |
| Range of temperature | -50℃~+125℃ | |
| Precision | ±1℃ | |
| Application | Joints in high or low voltage switchgears | |
| Battery life | ≥5 years | |
|
400 Passive wireless temperature sensor |
Wireless frequency | 470MHz |
| Communication distance | 150m in open area | |
| Sampling frequency | 15s | |
| Transmission frequency | 15s | |
| Power source | CT-powered, starting current≥5A | |
| Installation | alloy chip fixing | |
| Sensor probe | alloy bottom | |
| Range of temperature | -50℃~125℃ | |
| Precision | ±1℃ | |
| Application | Joints in high or low voltage switchgears | |
|
ATE100P/200P Outdoor wireless temperature sensor |
Wireless frequency | 470MHz |
| Communication distance | 150m in open area | |
| Sampling frequency | 25s | |
| Transmitting frequency | 25s-5min | |
| Power source | Battery | |
| Installation | bolted /Belt | |
| Range of temperature | -50℃~+150℃ | |
| Precision | ±0.5℃ | |
| Application | Voltage switchgears | |
| Battery life | ≥5 years | |
| Protection level | IP68 |
Writing
Typical Connection
