Acrel AMC96L-AI/M LCD display 96*96 panel single phase ampere meter with 4-20mA analog output
Contact Person : Dina Huang
Phone Number : 18761502682
WhatsApp : +8618761502682
| Minimum Order Quantity : | >=1 Pieces | Price : | $522.20 |
|---|---|---|---|
| Packaging Details : | It is packed in a crash bag and then put into a cardboard box. | Supply Ability : | 100000 Piece/Pieces per Month |
| Place of Origin: | Jiangsu, China | Brand Name: | Acrel |
|---|---|---|---|
| Model Number: | APM830 |
|
Detail Information |
|||
| Display Type: | Digital Only | Phase: | Three Phase |
|---|---|---|---|
| Measuring Energy Range: | 0-999999.99 KWh | Accuracy Class: | 0.2S |
| Output Voltage: | 220V | Operating Temperature: | -20~60℃ |
| Dimensions: | 96*96mm | Cut Out: | 92*92mm |
| Class: | 0.5S | Installation: | Embedded Installing |
| Communication: | DLT/645-2007 Protocol (support Freeze Function) | I/O: | 2 Digital Inputs + 2 Digital Outputs (2DI+2DO) |
| Port: | Shanghai | ||
| High Light: | 220V Harmonic Power Analyzer Meter,Power Analyzer Meter Panel Mounted,Acrel 220v power meter |
||
Product Description
|
Connection
|
|
3 phase 3 wire, 3 phase 4 wire
|
|
|
Frequency
|
|
50Hz
|
|
|
Input Voltage
|
Rated Voltage
|
AC 100V, 110V, 400V, 690V
|
|
|
|
Overload
|
1.2 times rated value(continuous); 2 times rated value(1 second)
|
|
|
|
Consumption
|
<0.5VA(per channel)
|
|
|
Input Current
|
Rated Voltage
|
AC 1A, 5A
|
|
|
|
Overload
|
1.2 times rated value(continuous); 2 times rated value(1 second)
|
|
|
|
Consumption
|
<0.5VA(per channel)
|
|
|
Accuracy
|
Voltage, current and power
|
Class 0.2S(APM801, APM830)
|
|
|
|
Active power
|
|
|
|
|
Reactive power
|
Class 2
|
|
|
|
Harmonic
|
1%(2-42nd), 2%(43-63rd)
|
|
|
Switch inputs
|
|
Passive contact inputs, built-in power supply
|
|
|
Relay outputs
|
|
Contact type: open contact in main part, changeover contact in module
Pulse capacity: 3A/AC250V, 3A/DC30V
|
|
|
Pulse output of energy
|
|
Output mode: Optocoupler pulse with open collector
Pulse constant: 4000(5A), 8000(1A) imp/kWh |
|
|
Analog output
|
|
DC0-20mA, 4-20mA, 0-5V, 1-5V output, accuracy class 0.5%,
Load resistance≤500Ω
|
|
|
Analog input
|
|
DC0-20mA, 4-20mA, 0-5V, 1-5V input, accuracy class 0.5%,
|
|
|
Storage card
|
|
Standard capacity: 4G, TF card up to 32G capacity
|
|
|
Communication
|
|
RS485(Modbus-RTU), Profibus(Profibus-DP),
Ethernet(Modbus-TCP, HTTP, DHCP)
|
|
|
Auxiliary power supply
|
|
AC/DC 85~265V or AC/DC 115~415V
|
|
|
Electromagnetic compatibility
|
|
IEC 61000 standard(Level 4)
|
|
|
Environment
|
Operating temperature
|
-20~65℃
|
|
|
|
Storing temperature
|
-20~70℃
|
|
|
|
Humidity
|
≤95%(No condensation)
|
|
|
|
Altitude
|
≤2500m
|
|
