Home ProductsHospital Isolated Power SystemAIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System
Contact Now

AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System

Minimum Order Quantity : >=1 Pieces Price : $1,618.00
Packaging Details : It is packed in a crash bag and then put into a cardboard box. Supply Ability : 100000 Piece/Pieces per Month
Place of Origin: Jiangsu, China Brand Name: Acrel
Model Number: AIM-M100

Detail Information
Usage: Insulation Monitoring Coil Structure: TOROIDAL
Coil Number: AUTOTRANSFORMER Power: 3.15KVA
Color: White Function: Temperature, Load, Centralized Monitoring
Voltage: AC220V Frequency: 50/60Hz
Certificate: CE Measure Current: <50μA
Port: Shanghai
High Light:

Medical Isolation Power Supply Monitoring Device

,

AIM-M100 n Power Supply Monitoring Device

Product Description

AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 0
Product Description

Hospital Isolated Medical Power Supply Insulation Monitor Device For Operation Theatre

The medical hospital isolated power supply system is mainly used in important Class 2 medical locations such as operating rooms, ICU/CCU intensive care unit, providing safe, reliable and continuous power distribution for the important equipment at these locations.
Medical IT system insulation monitoring and fault locating products (five-piece set) include AITR series medical
isolation transformer, AIM-M100 medical intelligent insulation monitoring instrument, AKH-0.66P26 current
transformer, ACLP10-24 DC power supply, and AID series(AID100, AID120, AID130, AID150) centralized alarm
and display instrument.
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 1
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 2
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 3
AIM-M100 Medical Intelligent Insulation Monitor
● Insulation monitoring for medical IT systems
● Load and temperature monitoring of isolation transformer
● Device disconnection monitoring
● LED indicators: On, Insulation, Overload, Overtemp
● Alarm relay output
● Test button
● RS485 (MODBUS-RTU) + CAN

Technical Parameter
Model
Model
AIM-M100

Auxiliary
Power
Voltage
AC220V

Frequency
50/60Hz

Maximum power consumption
<8VA


Insulation Monitoring
Relative percentage accuracy
0~±10%

Insulation resistance measuring range
10~999kΩ

Alarm value range
50~999kΩ

Response time
<2s


Current
Monitoring
Measuring range
2.1~5A

Measurement accuracy
5%

Display method
percentage display

Alarm value range
50~999kΩ

Temperature monitoring
Thermal resistor
PT100

Measuring range
-50℃~+200℃

Alarm value range
0℃~+200℃

Alarm output
Output
2 relay outputs (programmable)

contact capacity
AC 250V/3A DC30V/3A
Communication

2 RS485, Modbus-RTU
Rated impulse voltage/pollution class

4KV/3
EMC & EMR

IEC1326-2-4
Function
* real-time monitoring and fault alarming of the ground insulation resistance,
* transformer load current and transformer winding temperature of the monitored IT system,
* be used with insulation fault locator, remotely starting fault-locating and displaying locating results when there are
insulation faults,
* real-time monitor the line disconnection fault, temperature sensor disconnection fault and the functional grounding line
disconnection fault of the monitored system, and give the alarm indication within 2S after the fault occurs
* relay alarm output, LED alarm indication and other faults indication functions,
* used for centralized alarm and display instrument, test signal generator, insulation fault locator and upper computer management
software communications, and can monitor the operation status of IT system in real time.
* Events logging function, which can record alarm occurrence time and fault type and is convenient for operation personnel to
analyze the operation conditions of system and promptly eliminate the faults.
Packing & Delivery
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 4
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 5
It is packed in a crash bag and then put into a cardboard box.
Company Profile

AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 6
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 7
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 8
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 9
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 10
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 11
Jiangsu Acrel Electric Co.,LTD [Stock Code:300286.SZ ] is one of the few leading companies in China who provides various systematic of power monitoring, power control, energy management and electrical safety for smart grid users. Since June2003, we have always been focused on the research, production and sales of intelligent electric meters. We concentrate on providing products and services to help customers improve electricity and safety. So far we had the following comprehensive solutions for different applications: 35(10)/0.4KV substation automation system, building mounted photovoltaic(BMPV)system, power quality management system, energy management system, electrical fire monitoring system, IT distribution system for medical locations, precise distribution management system, power supply monitoring system for fire protection equipment, fire emergency lighting and evacuate indicating system, fire resistant doorsets monitoring system, smart lighting control system, Lithium battery management system and electric vehicle charging system.
Certifications
AIM-M100 Medical Isolation Power Supply Monitoring Device for Hospital Isolated System 12
FAQ
1. Where is your factory located ?
Our production base is located in Jiangyin City, Jiangsu Province, China;

2. How long would your equipment be used?
Generally, more than 10 years.

3. How long could I get my order?
Stock Products: shipping within 5 days.
Customized products: usually 10-15 days. It depends on your design and quantity.

4. What certificate do you have?
We have ISO9001, CE, IEC and so on.

5. Can I get a sample to check the quality?
Samples are no problem. We are glad to offer you some for test.

6. What's your MOQ?
At least one pcs.
