60x53mm centralized alarm insulation display instrument AID150 for hospital

Minimum Order Quantity : >=1 Pieces Price : $92.40
Packaging Details : It is packed in a crash bag and then put into a cardboard box. Supply Ability : 100000 Piece/Pieces per Month
Place of Origin: Jiangsu, China Brand Name: Acrel
Model Number: AID150

Detail Information

Panel Size: 60x53mm Installation: Panel
Pixel Pitch: 128*64 Dot Matrix Application: Alarm And Display
Port: Shanghai
High Light:

53mm insulation display

,

centralized alarm insulation display

Product Description

60x53mm centralized alarm insulation display instrument AID150 for hospital 0
Product Description
AID series alarm and display device is a remote display and sound and light alarm device by using advanced fieldbus communications technology. The device can be installed on the operating room or ICU, the medical staff can easily know the status of medical isolated power systems, and the type of fault when the system fails.
60x53mm centralized alarm insulation display instrument AID150 for hospital 1
60x53mm centralized alarm insulation display instrument AID150 for hospital 2
60x53mm centralized alarm insulation display instrument AID150 for hospital 3
- The insulation resistance alarm value, load current alarm value and transformer temperature alarm value of the system can be set remotely.
- When the system appears insulation fault, overload, transformer temperature over limit and wiring fault, alarm and display instrument gives out the corresponding sound and light alarm, and has the function of eliminating sound alarm.
- Using advanced fieldbus technology, the remote monitoring function can be realized by real-time data interaction with the insulation monitor.
- It can monitor one set of AIM-M100 insulation monitor and be used for installation by embedding into wall.
- It can be applied to monitor operating room or ICU only using single set of isolated power.
Technical Parameter
Model
AID150
Voltage
DC24V
Power Consumption
≤0.6W
Insulation Alarm Value Range
50~999KΩ
Load Current Alarm Settings
14A,18A,22A,28A,35A,45A
Temperature Alarm Value Range
0~200℃
Alarm
Sound and light alarm
Alarm Type
Insulation fault, overload, over-temperature, equipment failure
Communication
RS485 interface, MODBUS-RTU protocol
Display Method
128*32 LCD
Wiring
60x53mm centralized alarm insulation display instrument AID150 for hospital 4
Related Products
60x53mm centralized alarm insulation display instrument AID150 for hospital 5
60x53mm centralized alarm insulation display instrument AID150 for hospital 7
60x53mm centralized alarm insulation display instrument AID150 for hospital 9
60x53mm centralized alarm insulation display instrument AID150 for hospital 11
Packing & Delivery
60x53mm centralized alarm insulation display instrument AID150 for hospital 13
60x53mm centralized alarm insulation display instrument AID150 for hospital 14
It is packed in a crash bag and then put into a cardboard box.
Company Profile

60x53mm centralized alarm insulation display instrument AID150 for hospital 15
60x53mm centralized alarm insulation display instrument AID150 for hospital 16
60x53mm centralized alarm insulation display instrument AID150 for hospital 17
60x53mm centralized alarm insulation display instrument AID150 for hospital 18
60x53mm centralized alarm insulation display instrument AID150 for hospital 19
60x53mm centralized alarm insulation display instrument AID150 for hospital 20
Jiangsu Acrel Electric Co.,LTD [Stock Code:300286.SZ ] is one of the few leading companies in China who provides various systematic of power monitoring, power control, energy management and electrical safety for smart grid users. Since June2003, we have always been focused on the research, production and sales of intelligent electric meters. We concentrate on providing products and services to help customers improve electricity and safety. So far we had the following comprehensive solutions for different applications: 35(10)/0.4KV substation automation system, building mounted photovoltaic(BMPV)system, power quality management system, energy management system, electrical fire monitoring system, IT distribution system for medical locations, precise distribution management system, power supply monitoring system for fire protection equipment, fire emergency lighting and evacuate indicating system, fire resistant doorsets monitoring system, smart lighting control system, Lithium battery management system and electric vehicle charging system.
Certifications
60x53mm centralized alarm insulation display instrument AID150 for hospital 21
FAQ
1. Where is your factory located ?
Our production base is located in Jiangyin City, Jiangsu Province, China;

2. How long would your equipment be used?
Generally, more than 10 years.

3. How long could I get my order?
Stock Products: shipping within 5 days.
Customized products: usually 10-15 days. It depends on your design and quantity.

4. What certificate do you have?
We have ISO9001, CE, IEC and so on.

5. Can I get a sample to check the quality?
Samples are no problem. We are glad to offer you some for test.

6. What's your MOQ?
At least one pcs.
