AC220 Data Center Multi Circuit Energy Meter Rs485 Communication AMC16Z-ZA
Contact Person : Dina Huang
Phone Number : 18761502682
WhatsApp : +8618761502682
| Minimum Order Quantity : | 1 pcs | Price : | USD 175/PCS |
|---|---|---|---|
| Packaging Details : | Individually packed in big carton | Delivery Time : | 3 days |
| Supply Ability : | 10000/month |
| Place of Origin: | China | Brand Name: | Acrel |
|---|---|---|---|
| Certification: | CE | Model Number: | AMC16MA |
|
Detail Information |
|||
| Active Power: | Class 0.5S | Inlet: | 2 Channels |
|---|---|---|---|
| Outlet: | 36 Channels | Communication: | RS485 (Modbus-RTU) |
| Voltage: | AC 220/380V | Dimension(L*W*H): | 194*124*88mm |
| Installation: | DIN 35mm | ||
| High Light: | Class 0.5S Data Center Power Meter,Acrel Data Center Power Meter,Acrel power metering devices |
||
Product Description
AMC16MA Data Center Monitor Device:Designed specifically for the power supply management of server in the data center;Including 2 incoming line circuit and 36 outgoing line circuit.
Product Selection
| Name | Pic | Model | Main Function |
|
HMI
|
ATP007kt ATP010kt |
1.7 or 10 inch touch screen 2.Real-time monitoring and display voltage,current,power,energy,power quality,switch status,waveform curve and so on. 3.monitoring device alarm,communication and other parameters can be configured on the screen. 4. 2 RS485 and 1 Ethernet interface,and data can be uploaded by RS485 or RJ45. |
|
| AC incoming line monitoring module | AMC16Z-ZA |
1. Installation:DIN rail 35mm 2. Measurement:A+B independent 3 phase circuits, 6DI2DO,2 leakage current,1 temp. and humidity. 3. With DC 24V output power supply for outgoing line module and touch screen. 4. Communication:RS485 Modbus RTU |
|
| AC outgoing line monitoring module |
AMC16Z-FAK24 AMC16Z-FAK48 |
1. Installation:DIN rail 35mm 2. Can measure up to 16 circuit 3 phase or 48 circuit single phase 3. DC24V power supply 4. Communication:RS485 modbus RTU
|
|
| AC outgoing line current transformer | AKH-0.66W |
Current ratio:100A/50mA Common Specification: 100A/50mA |
|
| DC incoming line monitoring module | AMC16Z-ZD |
1.Installation:DIN Rail 35mm 2.Measurement:A+B independent circuits,6DI2DO,1 temp. And humidity. 3.With DC 24V output power supply for outgoing line module and touch screen. 4.Communication:RS485 modbus RTU |
|
| DC outgoing line monitoring module |
AMC16Z-FDK24 AMC16Z-FDK48 |
1. Installation:DIN Rail 35mm 2. Can measure up to 48 circuits DC outgoing line 3. DC24V power supply 4. Communication:RS485 modbus RTU
|
|
| DC incoming line insulation monitoring module | AMC16Z-ZJY |
1. Installation:DIN Rail 35mm 2. Measure A+B independent DC circuit ground insulation resistance of main bus 3. DC24V power supply 4. Communication:RS485 modbus RTU |
|
| DC outgoing line insulation monitoring module | AMC16Z-FJY |
1. Installation:DIN Rail 35mm 2. Measure 24 circuits ground insulation resistance of DC outgoing line |
|
| DC outgoing line hall effect current sensor | AHKC-BS |
Current ratio:100A/5V Common Specification: 100A/5V |
