Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485 ARTM-Pn

Minimum Order Quantity : 1 Piece Price : $155.40 / Piece
Place of Origin: Jiangsu, China Brand Name: ACREL
Model Number: ARTM-Pn

Detail Information

Application: Switch Cabinet, Switch Cabinet Color: Black
Panel Size: 96*96mm Pixel Pitch: 0.28mm
Power Supply: AC85-265V DC100-300V Maxium Energy Consumption: 8W
Installation Method: Embedded Accuracy: ±2℃
Digital Input Acquision: 4 Way 12V Input Communication: RS485 Modbus Rtu
Selling Units: Single Item Single Package Size : 10X10X10 Cm
Single Gross Weight: 0.600 Kg Package Type: Products Are Packed In Carton Box With Air Bubble Fim
High Light:

300286.SZ Wireless Temperature Sensor

,

Acrel Industrial Wireless Temperature Sensor

,

RS485 wireless temperature system

Product Description

Product Description



ARTM-Pn Wireless Temp Measuring Equipment

Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 0



General

ARTM-Pn wireless temperature measuring equipment has been developed in compliance with Specification for Wireless Temperature Measuring equipment, NB/T 42086-2016. It is suitable for 3-35kV indoor switchgears, including built-in switchgears, handcart switchgears, fixed switchgears and loop-net switchgears. It is also suitable for 0.4kV low-voltage switchgears such as fixed switchgears and drawer switchgears.



Features
● Wireless temperature measurement, maximum measuring 60 points;
● 4 digital inputs;
● 2 alarm relays;
● LCD display;
● Auxiliary power supply adapts with AC220V, DC220V, DC110V, AC110V;
● 1 RS485 serial communication, Modbus-RTU.



Technical Parameters

Items


Features

Power Source


AC85~265V,DC100~300V

Power Consumption


8W

Communication
Protocol

Modbus-RTU


Baud rate (bps)

2400,4800,9600,19200

Environment
Temperature

-10℃~55℃


Humidity

≤95%


Atmospheric pressure

86kPa~106kPa

MTBF


≥50000 h

Active wireless temperature sensor

Wireless frequency
2.4GHz/2.4GHz/470MHz



Communication distance
10m/10m/150m in open area



Sampling frequency
25s



Transmitting frequency
4min



Power source
Battery



Installation
Bolted/Strap-secured/tied with cable tie



Range of temperature
-40℃~+125℃



Precision
±2℃



Application
Joints in high or low voltage switchgears



Battery life
≥5 years

Passive wireless temperature sensor

Wireless frequency
470MHz



Communication distance
150m in open area



Sampling frequency
15s



Transmission frequency
15s



Power source
CT-powered, starting current≥5A



Installation
tied with cable tie/alloy chip fixing



Sensor probe
Isolated/alloy bottom



Range of temperature
-10℃~+125℃/-50℃~125℃



Precision
±2℃/±1℃



Application
Joints in high or low voltage switchgears




Configuration

Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 1
As above shown, the first configuration is only suitable for one cabinet.
The other two types of configurations can cross 5 cabinets.



Display

Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 2



Wiring

Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 3



Typical connnection

Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 4
Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 5
Acrel 300286.SZ Industrial Wireless Temperature Sensor With RS485  ARTM-Pn 6
