Home ProductsSplit Core Current Transformertoroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series
toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series
toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series
Contact Now

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series

Minimum Order Quantity : 1 Piece Delivery Time : 2-3 days
Place of Origin: Jiangsu, China Brand Name: Acrel
Certification: CE Model Number: AKH-0.66/I

Detail Information
Usage: Measure Current Coil Structure: TOROIDAL
Product Name: AKH-0.66/I Rated Frequency: 50/60Hz
Operating Temperature: -30℃-+70℃ Single Gross Weight: 0.400 Kg
Accuracy Class: Class 0.5
Highlight:

60Hz Split Core Current Transformer

,

plit Core Current Transformer AKH-0.66

,

60Hz split core current sensor

Product Description

Series Overview

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 0

Model Name Current Ratio (A) (Primary/Secondary) Accuracy Class and Rated Load (VA) Loop Count of Cable Perforation Size(mm)
Class 0.2 Class 0.5 Class 1.0   /
AKH-0.66/I 30I 15/5(1)       5
20/5(1)       4
25~30/5(1)       3
40~60/5(1)       2
75~100/5(1)       1 30x10/1
100/5(1)   1.5   1
150~200/5(1)   2.5   1
250/5(1)   3.75   1
300~450/5(1)   5   1
500/5(1)   10   1
600/5(1)   10   1
AKH-0.66/I 40I 10/5(1)     1.5 10 /
15/5(1)     1.5 8
20/5(1)     1.5 5
25~30/5(1)     1.5 4
40/5(1)     1.5 3
50~75/5(1)     1.5 2
100/5(1)     1.5 1 40x10/1
150/5(1)     2.5 1
200/5(1)   2.5   1
250/5(1)   3.75   1
300~450/5(1)   5   1
500~800/5(1)   10   1
1000/5(1) 10     1
AKH-0.66/I 60I 150/5(1)     2.5 1 60x10/1

60x6/1-2
200/5(1)   2.5   1
250/5(1)   3.75   1
300~450/5(1)   5   1
500~800/5(1)   10   1
1000~1250/5(1) 10     1
1500~2000/5(1) 20     1
2500/5(1) 30     1
AKH-0.66/I 80I 150/5(1)     2.5 1 80x10/1
200~250/5(1)   2.5   1
300~450/5(1)   5   1
500~800/5(1)   10   1
1000/1250/5(1) 10     1
1500~2000/5(1) 20     1
2500~3000/5(1) 30     1



Dimension

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 1

Installation Instruction

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 2

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 3

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 4

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 5

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I

Work Site Application

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 6

Company Profile

toroidal Coil 50/60Hz Low voltage Current Transformer AKH-0.66/I Series 7

Acrel Electric Co., Ltd. [Stock Code: 300286.SZ]
Founded in 2003, one of the few leading companies in China who provides various systematic solutions of power monitoring, power control, energy management and electrical safety for smart grid users. Substation automation system, power quality management system, energy management system, electrical fire monitoring system, IT distribution system for medical locations, precise distribution management system, FEPS power supply monitoring system, fire emergency lighting and evacuate indicating system, smart lighting control system and electric vehicle charging system.
