Acrel ANSVG 380V Static Var Generator Three Phase
Acrel ANSVG 380V Static Var Generator Three Phase Acrel ANSVG 380V Static Var Generator Three Phase Acrel ANSVG 380V Static Var Generator Three Phase Acrel ANSVG 380V Static Var Generator Three Phase Acrel ANSVG 380V Static Var Generator Three Phase
Contact Now

Acrel ANSVG 380V Static Var Generator Three Phase

Minimum Order Quantity : 1 Piece Price : $49,180.00 / Piece
Place of Origin: Jiangsu, China Brand Name: Acrel
Model Number: ANSVG: Static Var Generator

Detail Information
Display Type: Analog Only Phase: Three Phase
Measuring Energy Range: 0-380V Accuracy Class: 1.0
Output Voltage: 380V Operating Temperature: -10~45
Dimensions: 450*622*201mm Product Name: ANSVG: Static Var Generator
Communication: RS485 Port/ MODBUS Protocol Self-loss: ≤2%
Efficiency: >=98% Switching Frequency: 20KHz
Dimension(L*W*H): 450*622*201mm Response Time: ≤5ms
Compensation Effect: >=0.99 Operation Temperature: -10~45℃
Rated Voltage: 380V±15% Selling Units: Single Item
Single Package Size : 45X62.2X20.1 Cm Single Gross Weight: 2.000 Kg
Package Type: It Is Packed In A Crash Bag And Then Put Into A Cardboard Box.
High Light:

ANSVG Static Var Generator

,

380V Static Var Generator

,

Acrel Static Var Generator

Product Description

Acrel ANSVG 380V Static Var Generator Three Phase 0
Acrel ANSVG 380V Static Var Generator Three Phase 2


ANSVG: Static Var Generator

Static var generator is a new type of power electronics used to compensate for reactive power, harmonics, and regulation
imbalances. Mainly used in hospitals, commercial plazas, manufacturing, data centers, charging piles, airports, photovoltaic and other industries.
Function
1)Flexible compensation method:Compensating for reactive power from the load,filter out harmonics within 5th, 7th, 9th, 11th, and 13th;
2)Ability of managing three-phase imbalance;
3)Linear compensation,Response time ≤ 5ms;
4)Humanized human-computer interaction interface, which displays real-time power quality information of the system and the
ontology. This interface has the ability to control the device remotely and easy to operate;
5)Adopt imported IGBT which has high power density and high reliability;
6)Using DSP digital control system for high speed detection and calculation;
7)With remote communication interface, real-time monitoring through PC;
8)Standard modular design which reduces lead times and increases reliability and maintainability.
Acrel ANSVG 380V Static Var Generator Three Phase 3
Acrel ANSVG 380V Static Var Generator Three Phase 4
Dimension(L*W*H)
450*622*201mm

Response time
Full response time≤5ms,Instantaneous response time≤100μs

Compensation effect
≥0.99,Compensates for capacitive reactive and inductive reactive

Self-loss
≤2%

Efficiency
≥98%

Switching frequency
20KHz
Appearance
Acrel ANSVG 380V Static Var Generator Three Phase 5
Acrel ANSVG 380V Static Var Generator Three Phase 6
Acrel ANSVG 380V Static Var Generator Three Phase 7
Technical Parameters
item
value
Place of Origin
China

Jiangsu
Brand Name
Acrel
Model Number
ANSVG: Static Var Generator
Display Type
Analog Only
Phase
Three Phase
Measuring Energy Range
0-380V
Accuracy Class
1.0
Output Voltage
380V
Operating Temperature
-10~45
Dimensions
450*622*201mm
Product name
ANSVG: Static Var Generator
Communication
RS485 Port/ MODBUS Protocol
Self-loss
≤2%
Efficiency
≥98%
Switching frequency
20KHz
Dimension(L*W*H)
450*622*201mm
Response time
≤5ms
Compensation effect
≥0.99
Operation temperature
-10~45℃
Rated voltage
380V±15%
Interface
Acrel ANSVG 380V Static Var Generator Three Phase 8
Acrel ANSVG 380V Static Var Generator Three Phase 9
Acrel ANSVG 380V Static Var Generator Three Phase 10
Acrel ANSVG 380V Static Var Generator Three Phase 11
Company profile
Acrel ANSVG 380V Static Var Generator Three Phase 12
Acrel ANSVG 380V Static Var Generator Three Phase 13
Acrel ANSVG 380V Static Var Generator Three Phase 14
Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd., the manufacturer base located in Jiangyin, Wuxi City, is a pioneer
enterprise integrates the informatization and industrialization of Jiangsu province. It has a multiple function product test
center(CNAS certified), which can carry out a variety of tests on environment, electromagnetic compatibility, safety and
reliability. The production relies on the advanced information management system and strictly follow the ISO9001 management standard, which provide a guarantee for industrialization and large-scale implementation of the products. The annual capacity of the electrical meter is 2 million sets, 1.5 million power transformers and 10,000 sets of energy-saving cabinets.
Acrel Co., Ltd.[stock code: 300286.sz] is a high-tech enterprise integrates R&D, production, sales and service, since its
establishment, it committed to provide users with energy efficiency management and power security system solutions. Acrel Electric has a complete production line from cloud platform software to sensors. At present, more than 8,000 sets of various solutions are running all over the country, help users to realize the visual management of energy consumption, provide users the energy data services, and escort users an efficient and safe energy consumption.
Acrel ANSVG 380V Static Var Generator Three Phase 15
Acrel ANSVG 380V Static Var Generator Three Phase 16
Acrel ANSVG 380V Static Var Generator Three Phase 17
Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd.baojingjun@email.acrel.cn
Address:No.5,Dongmeng Road,Nanzha Town,Jiangyin City,Jiangsu Province.
Acrel ANSVG 380V Static Var Generator Three Phase 18
FAQ

1. Q: Where is your factory located ? How can I visit here ? Can your factory arrange transportation for me?

A: Our production base is located in Jiangyin City, Jiangsu Province, China; Which will take about 2 hours by car from Shanghai to our factory. We can arrange our driver to pick you up from your hotel when you arrive Shanghai.

2. Q: Does your factory have the design and development capabilities, can you factory accept customized products?

A: The staffs in our R&D department are well experienced in the Electric industry, with more than 10 years’ experience. We can make customized products especially for you; please kindly contact us for more

3. Q: How long could I get my order?

A: Stock Products: shipping within 5 days.
B: Customized products: usually 10-15 days. It depends on your design and quantity.

4. Q: How is your production management and quality control system?

A: All our product process follows up ISO9001. The strict implementation of ISO9001 assures to provide error–free products to our customers. We will show you these in our workshop during your visiting.

5. Q: How can I get a sample to check the quality?

A: We are glad to offer you samples for test. Leave us message of the item you want and your city address. We will offer you detail sample packing information, and select the best way to deliver it.
