AIM-T300 Industrial Isolated Power System Insulation Monitoring Device

Contact Now

AIM-T300 Industrial Isolated Power System Insulation Monitoring Device

Minimum Order Quantity :	1	Price :	USD 1480 pcs
Packaging Details :	9.6X9.6X7.6 cm	Delivery Time :	5-8 work days
Payment Terms :	L/C, T/T	Supply Ability :	2000000 pcs per year

Place of Origin:	Jiangsu, China	Brand Name:	Acrel
Certification:	ISO/CE	Model Number:	AIM-T300

Detail Information
Output Voltage:	AC85~265V	Dimensions:	969676mm
Display:	LCD	Accuracy Class:	1.0
Phase:	3	Communication:	RS485 Modbus RTU
Highlight:	AIM-T300 Industrial Isolated Power System , AIM-T300 Insulation Monitoring Device

Product Description

AIM-T300 Insulation Monitoring Device

● AC, DC main circuits

● AC/DC main circuits with directly connected DC components, such as rectifiers

● Systems with switch-mode power supplies

Specification

Type		AIM-T300	AIM-T500
Aux power supply	Voltage	AC85-265V
	Power Consumption	8W
IT system	Voltage	＜450V	＜800V
	Frequency	40-60Hz
Insulation monitoring	Measuring range	1kΩ-5MΩ	1kΩ-10MΩ
	Alarm range	10kΩ-5MΩ	10kΩ-10MΩ
	Accuracy	±10%
Communication		RS485(Modbus-RTU)
Standard		IEC61326-2-4
Operating alarm		-20-60℃	-15-55℃

LCD Display

AIM-T300 Industrial Isolated Power System Insulation Monitoring Device 0

Wiring

Typical connection
