Acrel AHKC-BS AC DC Hall Effect Current Sensor Static Converters For Motor Drivers
Contact Person : Dina Huang
Phone Number : 18761502682
WhatsApp : +8618761502682
| Minimum Order Quantity : | 1 Piece | Price : | $26.00 / Piece |
|---|
| Place of Origin: | Jiangsu, China | Brand Name: | ACREL |
|---|---|---|---|
| Model Number: | AHKC-LT |
|
Detail Information |
|||
| Usage: | Magnetic Sensor | Theory: | Hall Sensor |
|---|---|---|---|
| Output Signal: | Analog SENSOR | Product Name: | Close Type Open Ring Hall Effect Current Sensor With 0-200A |
| Input Current: | Ac / Dc 0-200A,0-800A | Power Supply: | ±15V |
| Rated Output: | 5/4V | Accuracy: | Class 1 |
| Measuring Aperture(mm): | 32.5 | Warranty: | 2 Years |
| Selling Units: | Single Item | Single Package Size : | 15X13X15 Cm |
| Single Gross Weight: | 0.420 Kg | Package Type: | Paper Carton With Air Bubble Films |
| High Light: | Hall Effect Current Sensor 200A,Hall Effect Current Sensor 5V,hall effect ct 200A |
||
Product Description
close type open ring hall effect current sensor with 0-200A input 5V output ac / dc
close type open ring hall effect current sensor is an open loop device based on the measuring principle of the hall effect, with a galvanic isolation between primary and secondary circuit. It provides accurate electronic measurement of DC, AC or pulsed currents.Hall current sensors are widely applicable for acquisition and feeback control of current signals in the current monitoring,inverter,solar power management,current cabinet,DC motor drive and UPS servo control systems.
| Model | Rated current | Power supply | Rated output | Hole size(mm) | Accuracy |
| AHKC-E | 0~(20-500)A | ±15v | 4/5v | φ20 | 1 |
| AHKC-LT | 0~(100-800)A | ±15v | 4/5v | φ32.5 | 1 |
| AHKC-EA | 0~(200-2000)A | ±15v | 4/5v | φ40 | 1 |
| AHKC-EB | 0~(200-2000)A | ±15v | 4/5v | φ60 | 1 |
| AHKC-BS | 0~(20-500)A | ±15v | 4/5v | 20.5*10.5 | 1 |
| AHKC-BSA | DC 0~(50-500)A | 12V/24V | 4~20mA | 20.5*10.5 | 1 |
| AHKC-F | 0~(200-1000)A | ±15v | 4/5v | 43*13 | 1 |
| AHKC-FA | 0~(200-1500)A | ±15v | 4/5v | 52*15 | 1 |
| AHKC-HAT | 0~(400-2000)A | ±15v | 4/5v | 52*32 | 1 |
| Model | Rated current | Power supply | Rated output | Hole size(mm) | Accuracy |
| AHKC-EKA | 0~(20-500)A | ±15v | 5v | φ20 | 1 |
| AHKC-EKAA | DC 0~(50-500)A | 12V/24V | 4~20mA | φ20 | 1 |
| AHKC-EKDA | AC 0~(50-500)A | 12V/24V | 4~20mA | φ20 | 1 |
| AHKC-EKB | 0~(200-1000)A | ±15v | 5v | φ40 | 1 |
| AHKC-EKBA | DC 0~(200-1000)A | 12V/24V | 4~20mA | φ40 | 1 |
| AHKC-EKBDA | AC 0~(200-1000)A | 12V/24V | 4~20mA | φ40 | 1 |
| AHKC-K | 0~(400-2000)A | ±15v | 5v | 64x16 | 1 |
| AHKC-KAA | DC 0~(400-2000)A | 12V/24V | 4~20mA | 64x16 | 1 |
| AHKC-KDA | AC 0~(400-2000)A | 12V/24V | 4~20mA | 64x16 | 1 |
| AHKC-H | 0~(500-3000)A | ±15v | 5v | 82x32 | 1 |
| AHKC-KA | 0~(500-5000)A | ±15v | 5v | 104x36 | 1 |
| AHKC-HB | 0~(2000-20000)A | ±15v | 5v | 132x52 | 1 |
| AHKC-HBAA | DC 0~(2000-20000)A | 12V/24V | 4~20mA | 132x52 | 1 |
| AHKC-HBDA | AC 0~(2000-20000)A | 12V/24V | 4~20mA | 132x52 | 1 |
